48VDC Power Supply 1000W Condor GPMP 900 48 Teal PN0870109

5140621-4-R
Refurbished
Magnetic Resonance Imaging
GE Healthcare
GE Healthcare
GE HealthCare
Outright
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • 90 - 264 VAC nominal input range
  • AC/DC Universal Input Power Supply
  • Overvoltage, over temperature and short circuit protection
  • Approved to UL, CSA and EN Standards

Other Buying Options


Condition: New

Product Overview

The 48VDC Power Supply 1000W Condor is used for the Power Distribution Unit (PDU) for the XGD cabinet in Magnetic Resonance Imaging (MRI) systems. The power supply is located on the right side of the top of the PDU that fits into the power cabinet assembly. The PDU consists of a transformer with a multi-tapped primary and two secondaries, a filter and a load center with circuit breakers to distribute power to the various peripherals in the MRI system. The power supply is used for the PDU to provide 48VDC power to the output connectors. It will be used to power fans within the cabinet, individual printed circuit boards and the control rack. The GPMP Series are universal input AC/DC power supplies with Power Factor Correction (PFC) with up to 900 Watts output power. This series operates for 90-264 VAC input voltage and offers DC output required for the industry. This power supply incorporates true inhibit, power fail alarm, power good signal and fan control. It also offers integral forced air cooling, peak rating is for 1 minute maximum 10% duty cycle and the noise measures 20 MHz bandwidth for differential mode. The measurements are across output terminals of the power supply and the 12V auxiliary outputs.

  • Additional Features

    • Power good LED
    • Low leakage
    • 12 V auxiliary output
    • Medical and commercial approvals
    • Working temperature -20° C to 70° C
